Core Features & Benefits
Middle Inertia Design
The MDMA152A1G features a middle inertia rotor (11.2 × 10⁻⁴ kg*m² without brake), specifically optimized for applications requiring balanced performance between rapid acceleration and stable load handling. This design provides:
- Enhanced stability for general industrial automation
- Reduced settling time in point-to-point positioning
- Smooth operation with moderate load inertia ratios
300% Overload Capacity
With a peak torque of 21.5 N*m (300% of rated torque), this motor handles demanding acceleration requirements and sudden load fluctuations without stalling.
Robust Mechanical Construction
- Oil Seal: The shaft includes an oil seal to prevent lubricant ingress - ideal for gearbox or pulley-coupled applications
- IP65 Rating: Standard protection against dust and water jets enables use in harsh workshop environments when used with oil-resistant cylindrical connectors
High-Resolution Feedback
Equipped with a 2500 P/R incremental encoder, providing precise position and speed feedback for high-resolution control loops. The motor also supports 17-bit incremental and 17-bit absolute encoder upgrades.
Wide Speed Range
Capable of operation from standstill up to 3000 RPM maximum speed, making it suitable for both high-speed machining and low-speed positioning applications.
IP65 Environmental Protection
Rated IP65 (excluding shaft penetration and connector pin parts), the motor is protected against dust ingress and low-pressure water jets, ensuring reliable operation in demanding industrial environments.
Frequently Asked Questions (FAQ)
Q: Is the Panasonic MDMA152A1G still in production?
A: No, this model is discontinued (End of Life) as of March 31, 2002.
Q: What driver is compatible with MDMA152A1G?
A: The recommended matching driver is the Panasonic MINAS A series MDDA153A1A (1.5KW servo driver).
Q: What is the inertia type of this motor?
A: The MDMA152A1G is a middle inertia type motor, designed for general-purpose automation applications requiring balanced performance.
Q: Does this motor have a holding brake?
A: No, this model (MDMA152A1G) is without holding brake. For brake-equipped versions, refer to series models with "H" suffix.
Q: Is the motor IP65 rated?
A: Yes, IP65 protection rating (excluding rotating portion of output shaft and connecting pin parts of connectors) when using oil-resistant cylindrical connectors.
Q: What is the rated speed of this motor?
A: Rated speed is 2000 RPM, with a maximum speed of 3000 RPM.
Q: What encoder does this motor use?
A: It uses a 2500 P/R incremental encoder, with support for 17-bit incremental and 17-bit absolute encoder upgrades.
Q: What is the peak torque?
A: Peak torque is 21.5 N*m (300% of rated torque).
Q: Is there a substitute model available?
A: Yes, the MDMA152A1C is listed as a substitute/replacement model.
Q: What is the warranty period?
A: The standard warranty period is one year from the date of purchase or 18 months from the month of manufacture in Panasonic's plant.
